Solid Edge 2021 Basics and Beyond
- Availability: Confirm prior to ordering
- Branding: minimum 50 pieces (add’l costs below)
- Check Freight Rates (branded products only)
Branding Options (v), Availability & Lead Times
- 1-Color Imprint: $2.00 ea.
- Promo-Page Insert: $2.50 ea. (full-color printed, single-sided page)
- Belly-Band Wrap: $2.50 ea. (full-color printed)
- Set-Up Charge: $45 per decoration
- Availability: Product availability changes daily, so please confirm your quantity is available prior to placing an order.
- Branded Products: allow 10 business days from proof approval for production. Branding options may be limited or unavailable based on product design or cover artwork.
- Unbranded Products: allow 3-5 business days for shipping. All Unbranded items receive FREE ground shipping in the US. Inquire for international shipping.
- RETURNS/CANCELLATIONS: All orders, branded or unbranded, are NON-CANCELLABLE and NON-RETURNABLE once a purchase order has been received.
Product Details
Overview
Solid Edge 2021 Basics and Beyond provides the student or practicing engineer with a basic introduction to 3D modeling using Solid Edge 2021. The topics are laid out in step-by-step format with examples and exercises at the end of each chapter to practice the concepts covered. The author uses numerous computer screenshots to explain software features.
Solid Edge is different from the other Computer Aided Designing software. It offers a rich set of tools known as Synchronous Modeling tools, which help you to create and edit design concepts very quickly and easily. Also, it helps you to design models keeping in mind the final design intent. However, you are required to know the rules of this software to avoid any errors. This book will be helpful if you are beginning to learn Solid Edge.
Table of Contents
1. Getting Started with Solid Edge 2021
2. Sketch Techniques
3. Extrude and Revolve Features
4. Placed Features
5. Patterned Geometry
6. Sweep Features
7. Loft Features
8. Additional Features and Multibody Parts
9. Modifying Parts
10. Assemblies
11. Drawings
12. Sheet Metal Design
13. Surface Design
14. Subdivision modeling
